BRAUN: 611950

Quantity Available:0

Coaxial Balloon Catheter, 30 mm dia. x 6 cm Balloon Length, 9 Fr Shaft Size, 10 Fr Introducer Size, 100 cm Usable Length, 1.5 ATM Rated Burst Pressure, Ultra Low-Profile, Sterile, Single-Use, Latex-Free, For PTV of the Pulmonary Valve

$31.36

/Each

More Information

The catheter is a coaxial design catheter with a balloon mounted on its distal tip. The lumen labeled with the balloon size is for balloon inflation while the through lumen allows the catheter to track over a guidewire. A radiopaque band(s) defines the center [or shoulders, if two] of the dilatation balloon. Each balloon inflates to the stated diameter and length at a specific pressure. The balloon size is ±10% at the nominal pressure. The rated burst pressure (RBP) is different for each size. Please check the package label for the RBP. It is important that the balloon not be inflated beyond the RBP.

More Informationa
Manufacturer	BRAUN
Balloon Diameter	30 mm
Tip Type	Distal, Tapered
Sterility	Sterile
Balloon Length	6 cm
Usage	Single-Use
Latex Free	Yes
Sterilization Method	Ethylene Oxide
Design	Ultra Low-Profile
Recommended Guidewire	0.035 in.
Usable Length	100 cm
Rated Burst Pressure	1.5 ATM
Introducer Size	10 Fr
Shaft Size	9 Fr
